MAIN FEATURES

Compact Design

64bit Quad Core 2.0GHZ Processor

1GB DDR3 RAM Memory

8GB integrated flash memory

2 USB2.0 connections

Micro SD card expansion slot

4K HDR suppport

Based on Android 7.1™

Hundreds of thousands of available applications!

KODI media player support

Easy streaming to iOS, Android™ devices & PC’s

DLNA - Easy playback over local network

4K 2160p output via HDMI2.0

Ethernet connection & built in Single-Band WiFi

Wired and wireless keyboard & mouse support

High quality digital surround sound via S/PDIF & HDMI

Low power consumption in Stand-By mode

TECHNICAL SPECIFICATIONS

Audio / Video Decoding

Input Rate: Max. 120Mbit/s
Aspect Ratio: 4:3, 16:9
Video Decoding: H.265/HEVC, MPEG-2, MP@ML, MPEG-4 Part 10 / H.264
Video Resolution: 720*480p/i, 720*576p/i,1280*720p, 1920*1080i/p, 2160p
Audio Decoding: MPEG-1 layer I/II, Mpeg2 layer II, Dolby Digital
Audio Mode: Left / Right / Stereo / Mono
Sampling Rate: 32, 44.1 & 48KHz

Interfaces:

HDMI: Type-A, Version 2.0
AV: Jack Type (CVBS video & Audio L/R output)
USB: 2x High Speed USB2.0 ports
SD Card: 1 MicroSD card slot (up to 32GB)
Ethernet: 10/100M RJ45
WiFi: Single-Band wifi
S/PDIF: Optical for digital audio output

System Resources

Main CPU: 64bit Quad Core 2.0GHZ Processor
Main GPU: Penta-Core Mali 450MP GPU
DDR: 1GB DDR3
EMMC: 8GB

Power Supply:

Type: External power supply
Input voltage: 110V - 240V AC
Output voltage: DC 12V (1A)
Stand-By power consumption: 0.5W

Physical Specifications:

Size (WxDxH): 140mm x 100mm x 31mm
Operation Temperature: 0ºC - 40ºC
Storage Temperature: -10ºC - 70ºC
Storage Humidity: 5-95% RH (Non Condensing)
